Detailed description

Applications:

This machine is highly efficient mixing equipment can be used in the pharmaceutical, food, chemical, light industry, machinery, electronics, mining, defense industry and scientific research enterprises of powdered materials of high uniformity of mixing.
Material in the mixing process without the centrifugal force, gravity segregation and non-hierarchical, the phenomenon of accumulation, the groups were in the poor under the weight ratio of mixing, mixing rate of 99.9%.
Loading factor is high, up to 80% (only 40% of the ordinary mixer) and mixing time is short, is a variety of mixer in an ideal product.
Equipment, compact structure, the use of variable speed drives (frequency or electromagnetic speed), easy to operate.
Throughout the transition for the arc barrel, and precision-polished, to GMP requirements.
How it works:

Mixing tank, through the two Y-joints installed in the main suspension, driven shaft end, two universal joints in space, both cross and perpendicular to each other. When the driving shaft is rotated drag, the universal joint in space again and again to make the barrel for translation, rotation and roll and other complex movements. Material in the tube for the body along the axial, radial and circumferential three-dimensional composite movement. Each barrel of a variety of materials flow, diffusion, doping, and finally was uniform state.

Technical parameters:
