Detailed description

Overview:
The machine is cross-flow continuous drying equipment for better ventilation sheet, strip, dry granular materials, for dehydrated vegetables, Chinese Herbal Medicine, and the like with high moisture content, the temperature does not allow the material is particularly suitable high ; the series dryers have a fast-drying, evaporation, high strength, good product quality advantages of the dehydrated cake-like paste materials, or to be made ​​by the granulation can be dried after the rod.

Features:
● You can adjust the amount of air, heating temperature, residence time and feed rate to achieve the best drying results.
● device configuration flexibility, you can use network systems and materials with a cooling system flush.
● Most of the air recycling, a high degree of energy saving.
● unique sub-air devices, so that hot air distributed more evenly, to ensure consistency of product quality.
● heat source can be steam, oil, electricity or coal-fired (oil) stove supporting

Principle： Material from the feeder network to bring in uniform ground floor, with the commonly used 12-60 mesh net stainless steel wire, dragged by the drive moves in the dryer. Dryer consists of several modules, each module separate hot air circulation, humidity and some exhaust fan by a dedicated exhaust, exhaust from the valve control, the heat from bottom to top or from top to bottom through the mesh belt to complete the material covered and the heat mass transfer process, the material away moisture. Network with slow-moving, speed can be freely adjust the temperature according to the material, the finished product after drying in a continuous feeder into income. Cell cycle up and down according to user needs with the flexibility, the number of units can be selected according to need. Application:
Dehydrated vegetables, pellet, monosodium glutamate, coconut, organic plastics, synthetic rubber, acrylic fibers, medicines, herbs, wooden products, plastic products, electronic components, aging, curing, etc.

Technical Data Sheet：

Note: some of the design parameters be adjusted depending on the material in order to design prevail.
