XF Series boiling dryer box
XF Series boiling dryer box
Steam or electric heating, the fuel can also be used (or coal) in hot air furnace hot air ...
Detailed description
Heating:
Steam or electric heating, the fuel can also be used (or coal) in hot air furnace hot air directly.
Applications:
Boiling dryers, also known as fluidized bed, since the application of more than 30 years, with continuous improvement, increase, in the pharmaceutical, chemical, food, widely used in food processing industries, such as: raw materials, medicine, medicine particles, granules, feed , plastic resin powder and granular materials dehumidification, drying. Material particle size in the range of 0.1-6mm, the best for the 0.5-3mm.
How it works:
Clean hot air into the bed through the allocation of the valve plate body, from the wet material into the feeder section formed by hot air fluidized bed, such as boiling water in the body jumps, so called boiling dryer (or machine), the hot air and a wide range of materials contact, so in a relatively short period of time can dry. From the bed of an entry, after a few minutes to a few minutes of 'boiling', automatically from the other side of the body out of bed.
Installation instructions:
Fluidized bed, cyclone and bag filter placed on a flat concrete floor can be no foot flat on the screw. Fan can be installed indoors or outdoors, the need for the base and foot screws. Layout according to the plant as appropriate adjustments.
Duct system should not leak, so as not to affect the drying effect.
Technical parameters:：
Steam or electric heating, the fuel can also be used (or coal) in hot air furnace hot air directly.
Applications:
Boiling dryers, also known as fluidized bed, since the application of more than 30 years, with continuous improvement, increase, in the pharmaceutical, chemical, food, widely used in food processing industries, such as: raw materials, medicine, medicine particles, granules, feed , plastic resin powder and granular materials dehumidification, drying. Material particle size in the range of 0.1-6mm, the best for the 0.5-3mm.
How it works:
Clean hot air into the bed through the allocation of the valve plate body, from the wet material into the feeder section formed by hot air fluidized bed, such as boiling water in the body jumps, so called boiling dryer (or machine), the hot air and a wide range of materials contact, so in a relatively short period of time can dry. From the bed of an entry, after a few minutes to a few minutes of 'boiling', automatically from the other side of the body out of bed.
Installation instructions:
Fluidized bed, cyclone and bag filter placed on a flat concrete floor can be no foot flat on the screw. Fan can be installed indoors or outdoors, the need for the base and foot screws. Layout according to the plant as appropriate adjustments.
Duct system should not leak, so as not to affect the drying effect.
Technical parameters:：
| Parameter | Bed area （m2） | Drying capacity (water kg / h) | Fans |
Inlet temperature (℃) |
Discharge temperature (℃) |
Heat can increase | |||
| Power | Wind pressure | Wind | Steam（kg/h） | Power（kw） | |||||
| XF-10A | 0.25 | 10～15 | 5.0 | 4900 | 2300 | 60～140 | 40～80 | 50 | 30 |
| XF-10B | 0.25 | 4 | 3800 | 2300 | |||||
| XF-20A | 0.5 |
20～25 |
7.5 | 5000 | 3100 | 100 | 60 | ||
| XF-20B | 0.5 | 5.5 | 3500 | 3100 | |||||
| XF-30A | 1.0 | 30～45 | 15 | 6000 | 4200 | 150 | 90 | ||
| XF-30B | 1.0 | 11 | 4700 | 4200 | |||||
| XF-50A | 2.0 | 50～80 | 22 | 7400 | 6000 | 250 | 150 | ||
| XF-50B | 2.0 | 18.5 | 5900 | 6000 | |||||
